Endless Websling 1ply
Endless Websling 1ply
Flat Webbing Sling Endless Single
- Diproduksi sesuai dengan EN 1492-1.
- Diproduksi dengan teknologi kualitas tertinggi.
- Perkuatan tepi dengan benang teknologi tinggi yang dianyam untuk melindungi dari keausan.
- Indikasi kapasitas beban yang dianyam superior.
- Kode warna sesuai dengan standar internasional.
- Nomor serial unik pada setiap sling web untuk tujuan pelacakan.
- Dilengkapi dengan sertifikat kesesuaian, label, dan buku petunjuk manual.
Select Model
Bobot Rendah
Penanganan dan transportasi mudah
Label selongsong pelindung
dilindungi secara optimal, diperkuat dengan tepi tenunan yg dianyam
Selain desain tahan sobek dengan lapisan kain, selongsong plastik kokoh melindungi tulisan dengan sempurna dari abrasi dan kotoran. Sisipan Webbing, yang dilengkapi sebagai standar, juga memperpanjang masa pakai.
Indikator kapasitas beban yang dijahit
Mudah dibaca meskipun kotor
Untuk keamanan aplikasi yang lebih baik, indikasi kapasitas beban dijahit dengan kuat pada tali. Kapasitas muatan tetap terbaca dengan jelas meskipun alat pengangkat sangat kotor.
Webbing Sling Endless Single Ply dijahit menggunakan kain poliester berkekuatan tinggi. Sling ini menggabungkan keunggulan sling bulat dan tali: area kontak yang lembut terhadap beban, panjang kerja yang bervariasi, sehingga ideal untuk digunakan dalam aplikasi yang sering berganti-ganti.
Anyaman Sling Endless Single dan Double Ply juga dapat dengan mudah digunakan dengan balok beban dan judul bab pembubutan. Untuk memastikan bahwa Anda selalu mengetahui kapasitas muatan, label berwarna sinyal dengan cetakan superior dijahit secara permanen pada sling. Anyaman Sling Endless Single dan Double Ply tahan terhadap tekanan yang besar dan tetap terbaca bahkan ketika sling sangat kotor.
Product Technical Information
-
Faktor Keamanan
7:1 -
Belt Layers
1 -
Label Protection
Yes -
Main Material
High-Tenacity Polyester -
Norms
EN 1492-1: 2000 -
Packaging Unit (PU)
pcs -
Temperature Range
-40°C bis +100°C -
Packaging Unit (PU) Content
1
Technical Drawings
Variants information
| Item Number | Item Name | WLL [kg] | Dimension L1 | WLL [t] | Weight for 1m | Weight Net | Weight per Meter | Colour |
|---|---|---|---|---|---|---|---|---|
| 2017543 | D1000-1M-21 | 1000 kg | 1 m | 1 t | 0.3 kg | 0.7 kg | 0.2 kg/m | Purple |
| 2017544 | D1000-2M-21 | 1000 kg | 2 m | 1 t | 0.3 kg | 0.8 kg | 0.2 kg/m | Purple |
| 2017545 | D1000-3M-21 | 1000 kg | 3 m | 1 t | 0.3 kg | 0.9 kg | 0.2 kg/m | Purple |
| 2017546 | D1000-4M-21 | 1000 kg | 4 m | 1 t | 0.3 kg | 1 kg | 0.2 kg/m | Purple |
| 2017547 | D1000-5M-21 | 1000 kg | 5 m | 1 t | 0.3 kg | 1.1 kg | 0.2 kg/m | Purple |
| 2017548 | D2000-1M-21 | 2000 kg | 1 m | 2 t | 0.5 kg | 0.8 kg | 0.4 kg/m | Green |
| 2017549 | D2000-2M-21 | 2000 kg | 2 m | 2 t | 0.5 kg | 1 kg | 0.4 kg/m | Green |
| 2017550 | D2000-3M-21 | 2000 kg | 3 m | 2 t | 0.5 kg | 1.2 kg | 0.4 kg/m | Green |
| 2017551 | D2000-4M-21 | 2000 kg | 4 m | 2 t | 0.5 kg | 1.4 kg | 0.4 kg/m | Green |
| 2017552 | D2000-5M-21 | 2000 kg | 5 m | 2 t | 0.5 kg | 1.6 kg | 0.4 kg/m | Green |
| 2017553 | D3000-1M-21 | 3000 kg | 1 m | 3 t | 0.7 kg | 0.9 kg | 0.5 kg/m | Yellow |
| 2017554 | D3000-2M-21 | 3000 kg | 2 m | 3 t | 0.7 kg | 1.2 kg | 0.5 kg/m | Yellow |
| 2017555 | D3000-3M-21 | 3000 kg | 3 m | 3 t | 0.7 kg | 1.5 kg | 0.5 kg/m | Yellow |
| 2017556 | D3000-4M-21 | 3000 kg | 4 m | 3 t | 0.7 kg | 1.8 kg | 0.5 kg/m | Yellow |
| 2017557 | D3000-5M-21 | 3000 kg | 5 m | 3 t | 0.7 kg | 2.1 kg | 0.5 kg/m | Yellow |
| 2017558 | D4000-2M-21 | 4000 kg | 2 m | 4 t | 0.9 kg | 1.5 kg | 0.7 kg/m | Grey |
| 2017559 | D4000-3M-21 | 4000 kg | 3 m | 4 t | 0.9 kg | 1.9 kg | 0.7 kg/m | Grey |
| 2017560 | D4000-4M-21 | 4000 kg | 4 m | 4 t | 0.9 kg | 2.3 kg | 0.7 kg/m | Grey |
| 2017561 | D4000-5M-21 | 4000 kg | 5 m | 4 t | 0.9 kg | 2.7 kg | 0.7 kg/m | Grey |
| 2017562 | D4000-6M-21 | 4000 kg | 6 m | 4 t | 0.9 kg | 3.1 kg | 0.7 kg/m | Grey |
| 2017563 | D4000-8M-21 | 4000 kg | 8 m | 4 t | 0.9 kg | 3.9 kg | 0.7 kg/m | Grey |
| 2017564 | D5000-2M-21 | 5000 kg | 2 m | 5 t | 1.2 kg | 1.8 kg | 0.9 kg/m | Red |
| 2017565 | D5000-3M-21 | 5000 kg | 3 m | 5 t | 1.2 kg | 2.3 kg | 0.9 kg/m | Red |
| 2017566 | D5000-4M-21 | 5000 kg | 4 m | 5 t | 1.2 kg | 2.8 kg | 0.9 kg/m | Red |
| 2017567 | D5000-5M-21 | 5000 kg | 5 m | 5 t | 1.2 kg | 3.3 kg | 0.9 kg/m | Red |
| 2017568 | D5000-6M-21 | 5000 kg | 6 m | 5 t | 1.2 kg | 3.8 kg | 0.9 kg/m | Red |
| 2017569 | D5000-8M-21 | 5000 kg | 8 m | 5 t | 1.2 kg | 4.8 kg | 0.9 kg/m | Red |
| 2017570 | D1000-6M-21 | 1000 kg | 6 m | 1 t | 0.3 kg | 1.2 kg | 0.2 kg/m | Purple |
| 2017571 | D1000-8M-21 | 1000 kg | 8 m | 1 t | 0.3 kg | 1.4 kg | 0.2 kg/m | Purple |
| 2017572 | D2000-6M-21 | 2000 kg | 6 m | 2 t | 0.5 kg | 1.8 kg | 0.4 kg/m | Green |
| 2017573 | D2000-8M-21 | 2000 kg | 8 m | 2 t | 0.5 kg | 2.2 kg | 0.4 kg/m | Green |
| 2017574 | D3000-6M-21 | 3000 kg | 6 m | 3 t | 0.7 kg | 2.4 kg | 0.5 kg/m | Yellow |
| 2017575 | D3000-8M-21 | 3000 kg | 8 m | 3 t | 0.7 kg | 3 kg | 0.5 kg/m | Yellow |
| 2020162 | D6000-2M-21 | 6000 kg | 2 m | 6 t | 1.4 kg | 3.1 kg | 1.1 kg/m | Brown |
| 2020163 | D6000-3M-21 | 6000 kg | 3 m | 6 t | 1.4 kg | 4.3 kg | 1.1 kg/m | Brown |
| 2020164 | D6000-4M-21 | 6000 kg | 4 m | 6 t | 1.4 kg | 5.5 kg | 1.1 kg/m | Brown |
| 2020165 | D6000-5M-21 | 6000 kg | 5 m | 6 t | 1.4 kg | 6.7 kg | 1.1 kg/m | Brown |
| 2020166 | D6000-6M-21 | 6000 kg | 6 m | 6 t | 1.4 kg | 7.9 kg | 1.1 kg/m | Brown |
| 2020167 | D6000-8M-21 | 6000 kg | 8 m | 6 t | 1.4 kg | 10.3 kg | 1.1 kg/m | Brown |
| 2020168 | D8000-2M-21 | 8000 kg | 2 m | 8 t | 1.8 kg | 3.9 kg | 1.5 kg/m | Biru |
| 2020169 | D8000-3M-21 | 8000 kg | 3 m | 8 t | 1.8 kg | 5.5 kg | 1.5 kg/m | Biru |
| 2020170 | D8000-4M-21 | 8000 kg | 4 m | 8 t | 1.8 kg | 7.1 kg | 1.5 kg/m | Biru |
| 2020171 | D8000-5M-21 | 8000 kg | 5 m | 8 t | 1.8 kg | 8.7 kg | 1.5 kg/m | Biru |
| 2020172 | D8000-6M-21 | 8000 kg | 6 m | 8 t | 1.8 kg | 10.3 kg | 1.5 kg/m | Biru |
| 2020173 | D8000-8M-21 | 8000 kg | 8 m | 8 t | 1.8 kg | 13.5 kg | 1.5 kg/m | Biru |
| 2020174 | D10000-2M-21 | 10000 kg | 2 m | 10 t | 2.4 kg | 5.2 kg | 2 kg/m | Orange |
| 2020175 | D10000-3M-21 | 10000 kg | 3 m | 10 t | 2.4 kg | 7.5 kg | 2 kg/m | Orange |
| 2020176 | D10000-4M-21 | 10000 kg | 4 m | 10 t | 2.4 kg | 9.8 kg | 2 kg/m | Orange |
| 2020177 | D10000-5M-21 | 10000 kg | 5 m | 10 t | 2.4 kg | 12.1 kg | 2 kg/m | Orange |
| 2020178 | D10000-6M-21 | 10000 kg | 6 m | 10 t | 2.4 kg | 14.4 kg | 2 kg/m | Orange |
| 2020179 | D10000-8M-21 | 10000 kg | 8 m | 10 t | 2.4 kg | 19 kg | 2 kg/m | Orange |
| 2021741 | D1000-10M-21 | 1000 kg | 10 m | 1 t | 0.3 kg | 1.6 kg | 0.2 kg/m | Purple |
| 2021742 | D2000-10M-21 | 2000 kg | 10 m | 2 t | 0.5 kg | 2.6 kg | 0.4 kg/m | Green |
| 2021743 | D4000-10M-21 | 4000 kg | 10 m | 4 t | 0.9 kg | 4.7 kg | 0.7 kg/m | Grey |
| 2021744 | D5000-10M-21 | 5000 kg | 10 m | 5 t | 1.2 kg | 5.8 kg | 0.9 kg/m | Red |
| 2021832 | D6000-10M-21 | 6000 kg | 10 m | 6 t | 1.4 kg | 12.7 kg | 1.1 kg/m | Brown |
| 2021833 | D8000-10M-21 | 8000 kg | 10 m | 8 t | 1.8 kg | 16.7 kg | 1.5 kg/m | Biru |
| 2021834 | D10000-10M-21 | 10000 kg | 10 m | 10 t | 2.4 kg | 23.6 kg | 2 kg/m | Orange |
| 2021835 | D3000-10M-21 | 3000 kg | 10 m | 3 t | 0.7 kg | 3.6 kg | 0.5 kg/m | Yellow |
