SpanSet USHA 14MM 4x39 FC RHOL Wire Ropes Main picture small
SpanSet USHA 14MM 4x39 FC RHOL Wire Ropes Small picture 1

Hyflex 4 RHOL

Hyflex 4 RHOL

General Purpose Ropes 4 Strands Conventional Products

Item Number: 2023926
SSID ERP Code: UM4X39OO-FCd14.0SZ1960G
USHA 14MM 4x39 FC RHOL
USHA 14MM 4x39 FC RHOL 1960 GALV
  • High quality flexible crane ropes as well as for wire rope sling asssemblies with design and load capacities comply to EN 13414-1.
  • Consistently good bend fatigue performance.
  • Destruction tested for guaranted strength.
  • Fully lubricated.
  • RHOL - Right Hand Ordinary Lay.

Select Model

Please contact customer service for purchase or more information

All wire rope that we supply are only high quality and certified products according to International Standard of BS EN 12385, API Spec 9A, ISO 2408 and SNI.

These wire Rope are manufactured by a company that has ISO 9001:2015 certification and also have 3rd party certification from ABS, DNV-GL and Lloyds.

Recommendations for Use

Do not use damaged wire ropes and slings with defects, such as wire breaks, bulges, bruises, kinks, severed core, heavy wear, rust damage or others. Do not exceed the specified load carrying capacity (WLL). Do not strike at a tilt angle exceeding 60°. Do not use wire ropes with broken strands. Do not use in contact with chemicals. Sling ropes may only be used for lifting and transporting loads and only by instructed persons. The regulation on the safe use of cranes (Crane Regulation) must be observed without fail (Suva-Form.1420. d).

Product Technical Information

  • Temperature Range: -40° C to + 100° C
  • Main Material: Steel
  • Packaging Unit (PU): pcs
  • Packaging Unit (PU) Content: 1

Item Number Item Name Rope Diameter Minimum Breaking Force [Kn] Minimum Breaking Force [Tn]
2023926
SSID ERP Code: UM4X39OO-FCd14.0SZ1960G 		USHA 14MM 4x39 FC RHOL 136 kN 13.9 t
2023927
SSID ERP Code: UM4X39OO-FCd16.0SZ1960G 		USHA 16MM 4x39 FC RHOL 16 mm 177 kN 18.1 t
2023928
SSID ERP Code: UM4X39OO-FCd18.0SZ1960G 		USHA 18MM 4x39 FC RHOL 18 mm 225 kN 22.9 t
2023929
SSID ERP Code: UM4X39OO-FCd20.0SZ1960G 		USHA 20MM 4x39 FC RHOL 20 mm 277 kN 28.3 t
2023930
SSID ERP Code: UM4X39OO-FCd22.0SZ1960G 		USHA 22MM 4x39 FC RHOL 22 mm 335 kN 34.2 t
2023931
SSID ERP Code: UM4X39OO-FCd24.0SZ1960G 		USHA 24MM 4x39 FC RHOL 24 mm 399 kN 40.7 t
2023932
SSID ERP Code: UM4X39OO-FCd25.0SZ1960G 		USHA 25MM 4x39 FC RHOL 25 mm 433 kN 44.2 t
2023933
SSID ERP Code: UM4X39OO-FCd26.0SZ1960G 		USHA 26MM 4x39 FC RHOL 26 mm 468 kN 47.8 t
2023934
SSID ERP Code: UM4X39OO-FCd28.0SZ1960G 		USHA 28MM 4x39 FC RHOL 28 mm 543 kN 55.4 t
2023935
SSID ERP Code: UM4X39OO-FCd30.0SZ1960G 		USHA 30MM 4x39 FC RHOL 30 mm 624 kN 63.6 t
2023936
SSID ERP Code: UM4X39OO-FCd32.0SZ1960G 		USHA 32MM 4x39 FC RHOL 32 mm 710 kN 72.4 t
2023937
SSID ERP Code: UM4X39OO-FCd33.5SZ1960G 		USHA 33.5MM 4x39 FC RHOL 33.5 mm 778 kN 79.3 t
2023938
SSID ERP Code: UM4X39OO-FCd34.0SZ1960G 		USHA 34MM 4x39 FC RHOL 801 kN 81.7 t
2023939
SSID ERP Code: UM4X39OO-FCd35.5SZ1960G 		USHA 35.5MM 4x39 FC RHOL 35.5 mm 873 kN 89.1 t
2023940
SSID ERP Code: UM4X39OO-FCd36.0SZ1960G 		USHA 36MM 4x39 FC RHOL 36 mm 898 kN 91.6 t
2023941
SSID ERP Code: UM4X39OO-FCd38.0SZ1960G 		USHA 38MM 4x39 FC RHOL 38 mm 1001 kN 102 t
