SupraPlus Round sling

SupraPlus Round sling

SupraPlus roundsling by SpanSet, designed for heavy-duty lifting tasks, offering durability and high load capacity for industrial use.

Item Number: 2002715
SSID ERP Code: RS-S500-1M
SupraPlus 500 1m
  • Slim and compact
  • Very high cut and wear resistance due to special ribbed profile
  • Robust, tear-resistant label protected by a transparent protective tube
  • Superior load capacity indication woven into the sleeve
  • Includes integrated loop to allow for easy retrofitting of an RFID transponder
  • Optimal wear protection due to reinforced fabric with interwoven textile filament

Select Model

Please contact customer service for purchase or more information
...

Textile fibre reinforcement

Longer service life

The textile filament woven into the outer sleeve offers reliable protection against tearing, reduces creasing and prevents further rupturing.

...

Compact cross-section

Compact thanks to improved production process

Thanks to the special matching of the sleeve and core, these round slings are very compact. The most important benefit: The compact round sling is not compressed in small crane hooks and the formation of creases is revented – creasing would decrease the strength and is therefore prohibited.

...

RFID optional

Attachment strap for retrofitting

All SpanSet gear can be fitted with an RFID transponder for asset management with IDXpert.

...

Protective sleeve label

Optimally protected, reinforced with a lining

In addition to the tear-resistant design with a fabric lining, a robust plastic sleeve perfectly protects the writing from abrasion and dirt. In lifting gear fitted with an RFID transponder, the transponder is integrated into the protective sleeve and is tear-resistant.

...

Woven load capacity indicator

Easy to read even when dirty

Speed is often of the essence in everyday work. To make sure you always use the right round sling, the load capacity indicator is firmly woven into the sleeve and can be read even when the sling is very dirty.

...

Unique grooved Structure

Versatile and reliable

Whether it‘s a straight pull, single lift or choke: The very compact SupraPlus round sling adapts to the load with virtually no creasing. The round sling is particular slim and finds sufficient contact area even in smaller crane hooks, without being compressed. This helps to effectively prevent any unwanted loss of load capacity. Universally applicable in all sectors of industry, SupraPlus meets the highest standards in terms of safety and quality worldwide.

With reinforced fabric and textile filament

The ribbed structure woven into the outer sleeve makes SupraPlus even more resistant to wear. The ribs are made of a high-performance polyester that is markedly more cut- and wear-resistant than conventional synthetic fibres. The textile filament woven into the sleeve offers additional wear protection. Additional safety that also has economical benefits. On request, the SupraPlus can also be fitted with an RFID chip for cloud based asset management with IDXpert. An attachment loop firmly sewn onto the round sling allows for easy and quick attachment of the IDXpert RFID tag.

Additional protection

Protective sleeves such as the single-sided SF-1 and the double-sided SF-2 or SpanSet NoCut are the ideal addition. They not only effectively protect the round sling from damage, but also facilitate the turning and rotating of sharp-edged loads and generally offer protection against sharp edges.

Product Technical Information

  • Tubing Type
    Ridges
  • Dimension L1 max
    30 m
  • Safety Factor
    7:1
  • Label Protection
    Yes
  • Main Material
    Polyester
  • Norms
    EN 1492-2: 2000
  • Packaging Unit (PU)
    pcs
  • Temperature Range
    -40° C to + 100° C
  • Packaging Unit (PU) Content
    1

Product downloads and manuals

...
Safe Lifting Guide
(en en_US)
Download
...
Roundslings instruction manual
(en en_US es fr it nl pl pt de_DE)
Download
...
Roundslings - Instruction manual
(de en es it nl fr_FR fr)
Download
...
Datasheet
Download
...
SupraPlus Brochure
(en_US en)
Download

Technical Drawings

Item Number Item Name WLL kg Dimension L1 WLL t Dimension L1 min Contact Thickness Under Load Weight Net Weight per Meter EAN Code Contact Width Under Load Colour
2002715 SupraPlus 500 1m 500 kg 1 m 0.5 t 0.5 m 5 mm 0.8 kg 0.2 kg/m 36 mm Olive
2002716 SupraPlus 500 2m 500 kg 2 m 0.5 t 0.5 m 5 mm 1.1 kg 0.2 kg/m 36 mm Olive
2002717 SupraPlus 1000 1m 1000 kg 1 m 1 t 0.5 m 6 mm 0.9 kg 0.3 kg/m 7610726101856 36 mm Purple
2002718 SupraPlus 1000 2m 1000 kg 2 m 1 t 0.5 m 6 mm 1.2 kg 0.3 kg/m 7610726101863 36 mm Purple
2002719 SupraPlus 2000 1m 2000 kg 1 m 2 t 0.5 m 8 mm 1 kg 0.5 kg/m 7610726101870 37 mm Green
2002720 SupraPlus 2000 2m 2000 kg 2 m 2 t 0.5 m 8 mm 1.5 kg 0.5 kg/m 7610726101894 37 mm Green
2002722 SupraPlus 3000 2m 3000 kg 2 m 3 t 0.75 m 10 mm 1.7 kg 0.6 kg/m 7610726101948 44 mm Yellow
2002723 SupraPlus 4000 1m 4000 kg 1 m 4 t 0.75 m 12 mm 1.4 kg 0.8 kg/m 7610726101979 52 mm Grey
2002724 SupraPlus 4000 2m 4000 kg 2 m 4 t 0.75 m 12 mm 2.3 kg 0.8 kg/m 7610726101993 52 mm Grey
2002725 SupraPlus 5000 1m 5000 kg 1 m 5 t 1 m 13 mm 1.5 kg 1 kg/m 59 mm Red
2002726 SupraPlus 5000 2m 5000 kg 2 m 5 t 1 m 13 mm 2.5 kg 1 kg/m 59 mm Red
2002727 SupraPlus 6000 1m 6000 kg 1 m 6 t 1 m 14 mm 1.8 kg 1.3 kg/m 65 mm Brown
2002728 SupraPlus 8000 1m 8000 kg 1 m 8 t 1 m 17 mm 2.2 kg 1.8 kg/m 68 mm Blue
2003203 SupraPlus 6000 3m 6000 kg 3 m 6 t 1 m 14 mm 4.4 kg 1.3 kg/m 65 mm Brown
2003205 SupraPlus 500 3m 500 kg 3 m 0.5 t 0.5 m 5 mm 1.4 kg 0.2 kg/m 36 mm Olive
2003207 SupraPlus 1000 3m 1000 kg 3 m 1 t 0.5 m 6 mm 1.6 kg 0.3 kg/m 36 mm Purple
2003208 SupraPlus 1000 4m 1000 kg 4 m 1 t 0.5 m 6 mm 1.9 kg 0.3 kg/m 36 mm Purple
2003209 SupraPlus 2000 3m 2000 kg 3 m 2 t 0.5 m 8 mm 2 kg 0.5 kg/m 7610726101900 37 mm Green
2003211 SupraPlus 3000 3m 3000 kg 3 m 3 t 0.75 m 10 mm 2.3 kg 0.6 kg/m 7610726101955 44 mm Yellow
2003212 SupraPlus 3000 4m 3000 kg 4 m 3 t 0.75 m 10 mm 2.9 kg 0.6 kg/m 7610726101962 44 mm Yellow
2003213 SupraPlus 4000 3m 4000 kg 3 m 4 t 0.75 m 12 mm 3.2 kg 0.8 kg/m 7610726102013 52 mm Grey
2003214 SupraPlus 4000 4m 4000 kg 4 m 4 t 0.75 m 12 mm 4.1 kg 0.8 kg/m 7610726102020 52 mm Grey
2003215 SupraPlus 5000 3m 5000 kg 3 m 5 t 1 m 13 mm 3.5 kg 1 kg/m 7610726102037 59 mm Red
2003216 SupraPlus 5000 4m 5000 kg 4 m 5 t 1 m 13 mm 4.5 kg 1 kg/m 59 mm Red
2003702 SupraPlus 8000 3m 8000 kg 3 m 8 t 1 m 17 mm 5.6 kg 1.8 kg/m 68 mm Blue
2003703 SupraPlus 8000 5m 8000 kg 5 m 8 t 1 m 17 mm 9 kg 1.8 kg/m 68 mm Blue
2003704 SupraPlus 1000 5m 1000 kg 5 m 1 t 0.5 m 6 mm 2.3 kg 0.3 kg/m 36 mm Purple
2003705 SupraPlus 1000 1.5m 1000 kg 1.5 m 1 t 0.5 m 6 mm 0.45 kg 0.3 kg/m 36 mm Purple
2003706 SupraPlus 2000 5m 2000 kg 5 m 2 t 0.5 m 8 mm 3 kg 0.5 kg/m 37 mm Green
2003707 SupraPlus 2000 1.5m 2000 kg 1.5 m 2 t 0.5 m 8 mm 0.75 kg 0.5 kg/m 7610726101887 37 mm Green
2003708 SupraPlus 3000 5m 3000 kg 5 m 3 t 0.75 m 10 mm 3.5 kg 0.6 kg/m 44 mm Yellow
2003710 SupraPlus 4000 5m 4000 kg 5 m 4 t 0.75 m 12 mm 5 kg 0.8 kg/m 52 mm Grey
2003712 SupraPlus 5000 5m 5000 kg 5 m 5 t 1 m 13 mm 5.5 kg 1 kg/m 59 mm Red
2003713 SupraPlus 5000 1.5m 5000 kg 1.5 m 5 t 1 m 13 mm 1.5 kg 1 kg/m 59 mm Red
2004197 SupraPlus 6000 5m 6000 kg 5 m 6 t 1 m 14 mm 7 kg 1.3 kg/m 65 mm Brown
2004198 SupraPlus 8000 4m 8000 kg 4 m 8 t 1 m 17 mm 7.3 kg 1.8 kg/m 68 mm Blue
2004199 SupraPlus 8000 2m 8000 kg 2 m 8 t 1 m 17 mm 3.9 kg 1.8 kg/m 68 mm Blue
2004201 SupraPlus 6000 4m 6000 kg 4 m 6 t 1 m 14 mm 5.7 kg 1.3 kg/m 65 mm Brown
2004202 SupraPlus 6000 1.5m 6000 kg 1.5 m 6 t 1 m 14 mm 1.95 kg 1.3 kg/m 65 mm Brown
2004650 SupraPlus 6000 2m 6000 kg 2 m 6 t 1 m 14 mm 3.1 kg 1.3 kg/m 65 mm Brown
2015116 SupraPlus 500 4m 500 kg 4 m 0.5 t 0.5 m 5 mm 1.7 kg 0.2 kg/m 36 mm Olive
2015117 SupraPlus 500 5m 500 kg 5 m 0.5 t 0.5 m 5 mm 2 kg 0.2 kg/m 36 mm Olive
2015120 SupraPlus 500 6m 500 kg 6 m 0.5 t 0.5 m 5 mm 2.3 kg 0.2 kg/m 36 mm Olive
2015127 SupraPlus 1000 6m 1000 kg 6 m 1 t 0.5 m 6 mm 2.6 kg 0.3 kg/m 36 mm Purple
2015128 SupraPlus 1000 8m 1000 kg 8 m 1 t 0.5 m 6 mm 3.3 kg 0.3 kg/m 36 mm Purple
2015129 SupraPlus 1000 10m 1000 kg 10 m 1 t 0.5 m 6 mm 4 kg 0.3 kg/m 36 mm Purple
2015134 SupraPlus 2000 2.5m 2000 kg 2.5 m 2 t 0.5 m 8 mm 1.25 kg 0.5 kg/m 37 mm Green
2015148 SupraPlus 3000 6m 3000 kg 6 m 3 t 0.75 m 10 mm 4.1 kg 0.6 kg/m 44 mm Yellow
2015149 SupraPlus 3000 8m 3000 kg 8 m 3 t 0.75 m 10 mm 5.3 kg 0.6 kg/m 44 mm Yellow
2015150 SupraPlus 3000 10m 3000 kg 10 m 3 t 0.75 m 10 mm 6.5 kg 0.6 kg/m 44 mm Yellow
2015159 SupraPlus 4000 6m 4000 kg 6 m 4 t 0.75 m 12 mm 5.9 kg 0.8 kg/m 52 mm Grey
2015160 SupraPlus 4000 10m 4000 kg 10 m 4 t 0.75 m 12 mm 9.5 kg 0.8 kg/m 52 mm Grey
2015166 SupraPlus 5000 0.75m 5000 kg 0.75 m 5 t 1 m 13 mm 0.75 kg 1 kg/m 59 mm Red
2015170 SupraPlus 5000 6m 5000 kg 6 m 5 t 1 m 13 mm 6.5 kg 1 kg/m 59 mm Red
2015171 SupraPlus 5000 8m 5000 kg 8 m 5 t 1 m 13 mm 8.5 kg 1 kg/m 59 mm Red
2015172 SupraPlus 5000 10m 5000 kg 10 m 5 t 1 m 13 mm 10.5 kg 1 kg/m 59 mm Red
2015175 SupraPlus 6000 6m 6000 kg 6 m 6 t 1 m 14 mm 8.3 kg 1.3 kg/m 65 mm Brown
2015177 SupraPlus 6000 8m 6000 kg 8 m 6 t 1 m 14 mm 10.9 kg 1.3 kg/m 65 mm Brown
2015179 SupraPlus 6000 10m 6000 kg 10 m 6 t 1 m 14 mm 13.5 kg 1.3 kg/m 65 mm Brown
2015180 SupraPlus 8000 1.5m 8000 kg 1.5 m 8 t 1 m 17 mm 2.7 kg 1.8 kg/m 68 mm Blue
2015181 SupraPlus 8000 1.75m 8000 kg 1.75 m 8 t 1 m 17 mm 3.15 kg 1.8 kg/m 68 mm Blue
2015184 SupraPlus 8000 6m 8000 kg 6 m 8 t 1 m 17 mm 10.7 kg 1.8 kg/m 68 mm Blue
2015185 SupraPlus 8000 7m 8000 kg 7 m 8 t 1 m 17 mm 12.4 kg 1.8 kg/m 68 mm Blue
2015186 SupraPlus 8000 8m 8000 kg 8 m 8 t 1 m 17 mm 14.1 kg 1.8 kg/m 68 mm Blue
2015187 SupraPlus 8000 10m 8000 kg 10 m 8 t 1 m 17 mm 17.5 kg 1.8 kg/m 68 mm Blue
2016847 SupraPlus 500 7m 500 kg 7 m 0.5 t 0.5 m 5 mm 2.6 kg 0.2 kg/m 36 mm Olive
2016848 SupraPlus 500 8m 500 kg 8 m 0.5 t 0.5 m 5 mm 2.9 kg 0.2 kg/m 36 mm Olive
2016849 SupraPlus 500 9m 500 kg 9 m 0.5 t 0.5 m 5 mm 3.2 kg 0.2 kg/m 36 mm Olive
2016850 SupraPlus 500 10m 500 kg 10 m 0.5 t 0.5 m 5 mm 3.5 kg 0.2 kg/m 36 mm Olive
2016852 SupraPlus 1000 7m 1000 kg 7 m 1 t 0.5 m 6 mm 3 kg 0.3 kg/m 36 mm Purple
2016853 SupraPlus 1000 9m 1000 kg 9 m 1 t 0.5 m 6 mm 3.7 kg 0.3 kg/m 36 mm Purple
2016857 SupraPlus 3000 7m 3000 kg 7 m 3 t 0.75 m 10 mm 4.7 kg 0.6 kg/m 44 mm Yellow
2016858 SupraPlus 3000 9m 3000 kg 9 m 3 t 0.75 m 10 mm 5.9 kg 0.6 kg/m 44 mm Yellow
2016860 SupraPlus 4000 7m 4000 kg 7 m 4 t 0.75 m 12 mm 6.8 kg 0.8 kg/m 52 mm Grey
2016861 SupraPlus 4000 8m 4000 kg 8 m 4 t 0.75 m 12 mm 7.7 kg 0.8 kg/m 52 mm Grey
2016863 SupraPlus 4000 9m 4000 kg 9 m 4 t 0.75 m 12 mm 8.6 kg 0.8 kg/m 52 mm Grey
2016865 SupraPlus 5000 7m 5000 kg 7 m 5 t 1 m 13 mm 7.5 kg 1 kg/m 59 mm Red
2016866 SupraPlus 5000 9m 5000 kg 9 m 5 t 1 m 13 mm 9.5 kg 1 kg/m 59 mm Red
2016868 SupraPlus 6000 7m 6000 kg 7 m 6 t 1 m 14 mm 9.6 kg 1.3 kg/m 65 mm Brown
2016869 SupraPlus 6000 9m 6000 kg 9 m 6 t 1 m 14 mm 12.2 kg 1.3 kg/m 65 mm Brown
2016870 SupraPlus 8000 9m 8000 kg 9 m 8 t 1 m 17 mm 15.8 kg 1.8 kg/m 68 mm Blue
